Servo Cold Forging Press Machine
Goodsjack 4 Column Cold Hydraulic Forging press adopt Siemens PLC hydraulic controller,the hydraulic press was mainly applied in tometalmaterials,cold forging,warm forging and extrusion molding,and punching mark,ligh stretching,cut edges and other materials.Such as cars,motorcycles,bicycles,cell phone case,LED radiator, watchcase,hardware tools.
E-mail:[email protected]
Product Details
Servo Cold Forging Press Machine
This cold forging press was mainly applies to metal materials,cold forging,hot forging and extrusion molding,and punching mark,light stretching,cut edges and other materials.Such LED radiator, auto spare parts, cellphone casing and hardware tools, watch case, hardware tools etc.Especially suitable for the precision molding parts.
Model | Units | Specifications | ||||||||||
DKHS-100 | DKHS-200 | DKHS-300 | DKHS-400 | DKHS-500 | DKHS-650 | DKHS-800 | DKHS-1000 | DKHS-1200 | DKHS-1500 | |||
master cylinder | rated capacity |
ton | 100 | 200 | 300 | 400 | 500 | 650 | 800 | 1000 | 1200 | 1500 |
stroke | mm | 300 | 400 | 400 | 400 | 500 | 500 | 500 | 500 | 500 | 400 | |
fast down speed |
mm/s | 180 | 160 | 160 | 230 | 230 | 170 | 190 | 210 | 190 | 220 | |
coining speed |
mm/s | 7-15 | 8-17 | 5-12 | 7-18 | 8-16 | 5-12 | 5-12 | 8-16 | 6-15 | 3-13 | |
return speed |
mm/s | 170 | 150 | 130 | 210 | 200 | 170 | 180 | 210 | 160 | 210 | |
system pressure | bar | 240 | 235 | 240 | 240 | 250 | 248 | 240 | 240 | 250 | 240 | |
knock-out cylinder | ejecting force |
ton | 15 | 30 | 30 | 40 | 40 | 50 | 50 | 60 | 80 | 100 |
stroke | mm | 200 | 200 | 200 | 200 | 250 | 250 | 250 | 250 | 250 | 200 | |
mandrel diameter |
mm | 40 | 50 | 50 | 60 | 60 | 80 | 80 | 80 | 80 | 100 | |
open height(slide to bolster) | mm | 600 | 700 | 700 | 700 | 800 | 900 | 1000 | 1100 | 1200 | 1050 | |
working table size |
L-R | mm | 500 | 700 | 700 | 800 | 800 | 1000 | 1000 | 1200 | 1300 | 1400 |
F-B | mm | 500 | 700 | 700 | 800 | 800 | 1000 | 1100 | 1200 | 1300 | 1400 | |
main motor power | KW | 8.6 | 16 | 23.6 | 34.6 | 34.6 | 37 | 60 | 74 | 90 | 110 | |
over all dimension |
L-R | mm | 1250 | 1680 | 1680 | 2600 | 2650 | 2940 | 3000 | 3660 | 3800 | 4150 |
F-B | mm | 1430 | 1780 | 1780 | 2100 | 2100 | 2100 | 2300 | 2450 | 2500 | 2680 | |
H | mm | 2850 | 3480 | 3500 | 3700 | 4050 | 4100 | 4320 | 4560 | 4720 | 4820 |
